High capacity LED lighting mounter 45000CPH with magnetic linear motor pick and place machine
Feaure of Machine
1.Single module magnetic linear motor multi-functional pick and place machine.
2.Precision mounting head system:
12 nozzles, group picking and splitting and splitting and splitting, can meet the installation requirements of different components. Each placement head is independently controlled by an independent servo motor, ensuring that the machine can pick and place more accurately at higher speeds.
3.Mounting components: LED, capacitor, resistor, Shaped components.
4.Components size: Min size: 0402. Max height: 15mm.
5.Application: Power driver, electric board, lens, linear bulb, household appliance, LED
tube/bulb/panel/display/down-light/lens/Ceiling light etc.
With the rapid development of the LED industry, the quality requirements for automation equipment products are getting higher and higher, and the ETON placement machine is equipped with MARK point positioning vision + equipment recognition functions. Pursuing high speed and high stability, it is a cost-effective and practical LED multi-function placement machine.
Main Parameter
| Pick and place machine module | HT-E8S-1200 |
| Machine mounting speed | 45000 CPH(CHIP PER HOUR) |
| Machine Dimension | 2550*1650*1550 MM |
| PCB Length Width | Max:1200*500 mm Min:100*100 mm |
| Mounting Mode | Group picking and separate placing, separate picking and separate placing |
| Power | 380 AC 50HZ |
| Power Consumption | 4 KW |
| X,Y,Z Axis Drive way | High-end magnetic linear motor+ servo motor |
Company Introduction
ETON Automation Equipment Co., Ltd.is a professional manufacturer focusing in pick and place machine. Right now, we have integrated R&D, production and sales together.
With good quality, competitive price, easy operation and energy saving, our products are very popular in domestic and oversea market. And all of our machines are wildly used in electronic circuit, photovoltaic, LED industry, instruments and apparatuses.
Up to now, our products are already sold in many countries such as USA , KOREA , INDIA , GERMANY , EGYPT , TURKEY , VIETNAM , TUNISIA , THAILAND more than 30 countries.We will continue to make great efforts to satisfy the customers' requirement.
SMT Pick and Place Machine: It is our primate product, the working teams have always been dedicated to the research and development of SMT machine, which has become a widely recognized brand by customers.
Service
1. Maintenance period:1 year
2. Provide free online training and remote guidance
3. oversea and local engineer and office provide free installation and training door-to-door
4. Software is R&D independently by ETON, provide free upgrade whole lifetime
5. Make regular return visits to collect customer information and provide customers with the latest production technology and equipment information regularly
FAQ
Q: What is the payment way ?
A:We accept the payment terms: T/T.
Q: Is it hard to use these machines?
A: No, not hard at all. For our previous clients, at most 2 days is enough to learn to operate the machines.
Q: Can you provide a whole line solution?
A: Yes, we can .We can supply SMT line and LED production line.
|
|
